Smart Warehouse Rack System Intelligent Storage Vertical Carousel Module 17000kg

Basic Info

Model NO.	GHZ-500
After-sales Service	Engineer Service
Warranty	12 Months
Usage	Tool Rack, Clothing, Tools, Supermarket, Industrial, Warehouse Rack
Material	Steel and Reinforced Concrete
Structure	Cantilever Rack
Type	Multi-Level Racking
Mobility	Combined
Height	5-15m
Weight	17000 Kg
Closed	Closed
Development	New Type
Serviceability	Common Use
Width	1930mm - 3730mm
Transport Package	Wooden Package
Trademark	CLIP-ON
Origin	China
Production Capacity	10000 Sets Per Year

Product Description

DESCRIPTIONVERTICAL CAROUSEL MODULE
GHZ150/GHZ350/GHZ500 ADVANTAGE
1. Reduction in labor, with data showing an increase in efficiency of more than 2.5 times the amount;
2, Significantly improve sorting accuracy and reduce sorting errors
3. Significant savings in floor space, maximizing the use of storage space and eliminating the use of shelving materials
4. Improved safety for operators and goods
5. Fast return on assets, typically 12 months to recover equipment investment
6. Efficient retrieval of multiple materials

SPECIFICATION

Model	GHZ150	GHZ350	GHZ500
Width	1905mm - 3905mm	1930mm - 4330mm	1930mm - 3730mm
Height	2360mm - 7510mm	2360mm - 8600mm	2360mm - 8600mm
	1250 mm	1320 mm	1320 mm
	1440mm	1520 mm	1520mm
	1630mm	1720 mm	1720 mm
Bin Size
Width	1250mm - 3250mm	1250mm - 3650mm	1250 - 3050mm
High	210/230/260/280/310/340/360mm	260/300/340/370/415/450/490/528mm	306/356/407/458mm
Depth	420 mm	420 mm	420 mm
	520 mm	520mm	520mm
	620mm	620mm	620 mm
Maximum partial load	600 kg	1200 kg	1500 kg
Maximum load	6000 kg	12500 kg	17000 kg
Maximum load per bucket	150 kg	350 kg	550 kg

FEATURE

• Modular design, can be a single machine can be combined
• The ergonomic design of the goods directly to the operator
• Adapt to a variety of conventional storage needs of a variety of storage boxes and containers
• Emergency brake to ensure safety; further more top safety design options: light curtain, overload protection, etc.
• Visualized operation, simple and convenient
• Available with double chain and double motor design to increase load redundancy
• Smooth connection and expansion with ERP
• In addition to customizing various bins, we can also customize automatic doors, multiple access ports, high clean storage, refrigerated storage, etc.

DISPLAY
PRODUCTIONABOUT US
Clip-on (Jiangsu) Technologies, Was established in 2008. The company's R&D and production headquarters is located in Lianhu Industrial Park, Danyang City, Jiangsu Province. It is 4.5 kilometers away from Danyang West Exit of Shanghai-Chengdu Expressway and 6.5 kilometers away from Danyang Station of Intercity High-speed Railway. The transportation is very convenient.At the beginning of the company's establishment, it was an enterprise that sold industrial accessories, consumables (MRO) and special mechanical and electrical products, research, development, production and sales. Products are exported to Europe, America and Southeast Asia.In order to cater to the development trend of Industry 4.0, solve storage and management problems for our customers, and provide personalized services, the company established an intelligent storage research and development team in 2015, dedicated to the planning, design and development of intelligent storage equipment and modern and efficient internal logistics solutions Manufacturing, serving intelligent manufacturing with intelligent manufacturing, and jointly realizing China's industrial upgrading is our mission.Our main products are intelligent lifting cabinets, intelligent horizontal rotary cabinets, intelligent vertical rotary cabinets, intelligent distribution combination management warehouses, intelligent combination packaging warehouse sales warehouses for various materials, materials and parts, which are widely used in mechanical and electronic manufacturing, pharmaceutical and chemical industries, food and beverage, new energy, energy and electricity, mining and metallurgy, infrastructure, public health, wholesale and retail, etc.
QUALITY ASSURANCE AND SERVICE
1. Have a complete rigorous management, production and inspection processes to control the quality and avoid detail mistake
2. Design and produce ability
3. Rigorous inspection including incoming inspection, flaw detection etc., and double check is a must.
4. Advanced factory facility ensure
5. Response to any inquiry within 24 HRS with design or efficient solution from our engineer or tech supporter.
6. Provide professional customization service according to client's requirements
7. on time delivery, as we have rigorous production schedule and profession follow-up process
8. Moderate price and professional serviceWelcome to your inquiry!
