Starsplas WPC Electric Control Profiling Machine Automation Unloading System for WPC Flooring Production

Basic Info

Model NO.	SP-P6+6
Position2	6+6
Transport Package	Container, Warp Film
Specification	Stainless steel
Trademark	StarsPlas
Origin	China
HS Code	8465920000
Production Capacity	20-90m/Min

Product Description

01 Full-automatic ProfilingThe whole line is fully automatic production, including the feeding of the incoming sheet, the transition between the slotting machines and the finished products

02
High speed/High capacity
The longitudinal no-load speed of high-speed production line can reach 90m/min, while the current conventional production line speed is only 50-70m/min.

03 High stability & Low defective rateHigh precision tool shaft and cutting tools are used inside the equipment to ensure stable production and reduce the rate of defective products.

04 Thorough dust controlSlotting equipment is sealed with a fully closed enclosure, and the dust control rate can reach more than 95%

System Composition

Sawing Machine +Profiling Machine
Processing Length	600~2450mm
Processing Width	970~1300mm
Thickness	3.0~10.0mm
After cutting	Length(600~1850mm)×Width (110~475mm)
After processing lock	Length(600~1850mm)×Width (100~475mm)
Feed Drive Unit	3.7kW×4P 1 unit Inverter Control
Feeding Speed	8 ~40m/min ( With the increase of thickness and Slice number, feed rate decreasing)
Caterpillar Chain	N75 type Chain×2
Caterpillar Chain Guide	N75 resin type
Main Spindle	22kW×2P 1 unit 3000rpm

Profiling Machine
Vertical Slotting Machine	2.2kW×4P 1 unit Inverter Control,Installed on the Left. 20~90m/min,Ring Belt
Vertical Double End Milling
Rack Truck	Left fixed, right mobile side Installation Liner Guide,Digital, 1.1kw×4P, 1 unit
Feed Drive Unit	Right mobile side Installation,7.5kW×4P Inverter Control 1 unit 20 ~90m/min(Normal 60m/min)
Caterpillar Chain	N30 type Chain,2 Column with Urethane Plates(Flat type)
Caterpillar Chain Guide	N30 ceramic type
Air Blow for Chain	Right/Left & Inlet/Outlet, Total 4 points
Lubrication Pump	For Caterpillar Chain Guide, Auto-Lubrication type 25W 1 unit,For Traveling Drive Sleeve & Column Screw.
Up Pressing Device	Vapour-pressure type belt pressing
Spindle Movement	Manual type Mechanical digital position indicator

Automation Loading system
OperationControl system	1. PLC program controller: Siemens2.Touch Screen: Siemens3.Frequency converter:Siemens
Servo system	Servo motor: SiemensUsing the operating system developed by ourselves, the logic program is rigorous and reasonable.
Sensor system	1. Photoelectric switch: SICK2. Proximity Switch: SICK3. Magnetic Switch: SMC
Electrical control system	1. All tests and protection shall adopt double safety protection measures.2. Contactor, intermediate relay: Mitsubishi,Chint Group3. Drag chain cable: GB high-speed flexible sports cable (North American UL standard)
Pneumatic control system	Vacuum System: Pineb2. Oil-water separator: SMC full pressure automatic drainage type3. Vacuum sucker: self-developed silicone sucker
Mechanical shifting parameters	Sheet length: 800~1550 mmSheet width: 800-1250mmSingle weight: maximum 30 KGSinglethickness: 3-8mmMaximumStacking height: 800mm
Input gas source	Stable air pressure 0.6-0.8Mpa
Working voltage	Three phase 380 V, 50 Hz, single phase 220 V, 50 Hz
Working height	According to the working height of the main engine on site. (900-1250mm)
OperationControl system	1. PLC program controller: Siemens2.Touch Screen: Siemens3.Frequency converter:Siemens
Servo system	Servo motor: SiemensUsing the operating system developed by ourselves, the logic program is rigorous and reasonable.
Sensor system	1. Photoelectric switch: SICK2. Proximity Switch: SICK3. Magnetic Switch: SMC
